Wooden/Timber Direct Drive Cooling Towers - Lower to Medium Capacity Solutions
Paltech's Wooden/Timber Single & Double Flow Induced Draft Crossflow Cooling Towers with Direct Drive Systems are engineered for lower to medium capacity cooling applications, combining traditional timber construction with modern mechanical efficiency. These robust cooling systems feature direct drive mechanisms eliminating belt drives and associated maintenance complexities, ensuring reliable operation and simplified service requirements.
Our direct drive cooling towers are equipped with fans up to 8 feet in diameter, featuring multi-blade cast Aluminum/FRP adjustable pitch fan blades, M.S. fabricated H.D.G./S.S. hubs, and S.S. hardware ensuring efficient cooling performance. The direct coupling configuration with low RPM motors provides simplified mechanical design, reduced maintenance overhead, and enhanced reliability compared to belt-driven systems.
These cooling towers are available in both single flow and double flow induced draft crossflow configurations, providing flexibility for specific capacity requirements and installation constraints. The traditional timber construction, combined with modern mechanical components, delivers proven reliability and cost-effectiveness for applications requiring medium-capacity cooling solutions.
Why Choose Paltech™ Direct Drive Cooling Towers?
Quality Products & Reliable Services
Paltech™ ensures top-tier quality and dependable services for all cooling tower components, backed by over 39 years of manufacturing excellence.
39+ Years of Manufacturing Excellence
Decades of experience in manufacturing ensure superior product quality, performance, and reliability across diverse industrial applications.
11,000+ Satisfied Clients
A vast client base trusts Paltech™ for their industrial cooling solutions worldwide, demonstrating proven track record and customer satisfaction.
Global Export Network
Our cooling towers are supplied globally to 46+ countries, meeting international standards and diverse industrial requirements.
Technical Specifications & Components
Detailed insights into core components, operational features, and engineering specifications designed for reliable performance.
Motor Specifications
- Special low R.P.M., totally enclosed vertical motor designed for cooling tower applications
- Flange type configuration with enlarged and threaded shaft, sealed top for weatherproof operation
- Totally weatherproof construction with IP-55 protection rating
- Suitable for operation in heated and humid environments typical of cooling tower installations
Fan Drive System
- Direct coupling with low RPM motors (vertical flange-mounted with sealed top and enlarged threaded shaft)
- Simplified mechanical design eliminating belt drives and associated maintenance requirements
- Optional gear-driven fan systems available for more demanding applications requiring enhanced control
Fan Specifications
- Fans with diameters up to 8 feet for lower to medium capacity cooling applications
- Multi-blade cast Aluminum/FRP adjustable pitch fan blades for optimal air flow control
- M.S. fabricated H.D.G./S.S. hub with S.S. hardware ensuring durability and corrosion resistance
- Specifically designed for lower to medium capacity cooling needs with proven reliability
Key Structural Components
Preservative Timber Construction
Main structural components and lightweight sections crafted from selected preservative timber ensuring durability, resistance to decay, and long-term structural integrity.
Galvanized Joint Fastening
All structural joints bolted using galvanized bolts with Stainless Steel or Phosphor Bronze hardware available as upgrade options for enhanced corrosion resistance.
Uniform Water Distribution System
Hot water basin equipped with distribution box ensuring even water dispersion throughout the basin, with subsequent splashing through spray target nozzles for optimal cooling.
Key Cooling Components
Weather-Resistant Cladding
Standard cladding consists of profile corrugated sheets with joints designed to shed water only inside the cooling tower, preventing external moisture ingress.
Advanced Drift Eliminators
Specially designed eliminators available in single-pass to four-pass patterns made from various materials, minimizing bleed losses and water consumption.
High-Efficiency Fill Systems
Fill bars designed to maximize splash surface and wetted surface area, resulting in superior heat transfer rates and optimal cooling performance.
Versatile Fill Support Systems
Wooden/PVC fills supported on wooden stringers or S.S. wire mesh grids ensuring secure positioning. Various fill materials and shapes available for specific design requirements.
Ideal Applications & Use Cases
Lower to Medium Capacity Industrial Cooling
Manufacturing Facilities
Process Cooling Applications
HVAC Systems
Food Processing Industries
Textile Manufacturing
Chemical Processing
Small to Medium Power Plants
Commercial Buildings
Interested in Direct Drive Cooling Towers?
Get detailed information about our Wooden/Timber Direct Drive Systems and discover how they can benefit your lower to medium capacity cooling applications. Request comprehensive specifications and expert consultation.
